Reference: 5136CF
Star 5136CF, 36", Electric, Radiant Charbroiler
19,359
Out of stock
Ekuep fulfilled
Rowad Points
Rowad members can earn points that can be redeemed for various amazing rewards.
This product is currently out of stock.
Qty
Extra Services
Get A Price Match
+ 5% Store Credit
Suggested Alternative
We believe this product is a perfect alternative of what you are looking for
Nieco JF143-2E BroilVection™ Electric Automatic Conveyor Broiler
74,307
(VAT Included)Nieco JF143-2E BroilVection™ Electric Automatic Conveyor Broiler
- Heavy-duty electric automatic conveyor broiler designed for high-volume quick-service restaurants, burger concepts, central kitchens, and other demanding commercial foodservice operations.
- Features Nieco's patented BroilVection™ technology, designed to provide consistent cooking while giving operators greater control over the broiling environment.
- Automatic conveyor cooking moves products continuously through the broiler, helping deliver repeatable results while reducing the need for constant operator attention.
- Equipped with a dedicated meat conveyor belt with adjustable belt-speed control, allowing the broil time to be changed according to the product and required doneness.
- Integrated bun platen allows buns to be toasted as part of the same production workflow, reducing the need for a separate bun toaster. The platen has its own temperature control.
- Designed to handle multiple food products, making it suitable for burgers and other proteins as well as buns and selected menu items.
- Load Stabilizer Control regulates energy input when the broiler is operating under load, helping maintain consistent cooking performance during busy service periods.
- Belt reverse function allows the operator to temporarily reverse the conveyor direction to help clear a belt jam.
- Simple operator controls include belt-speed adjustment, main power switch, power indicator, load stabilizer, bun-platen temperature control, and belt reverse control.
- Electric heating elements provide the cooking heat without requiring a gas connection.
- Designed for continuous high-volume production, making it particularly suitable for operations where speed, repeatability, and reduced operator handling are priorities.
- Components are designed for removal and routine cleaning, with the manufacturer's manual providing dedicated procedures for the PTFE sheets, heat shield, discharge awning, patty catch pan, bun blade, grease box, chimney, and conveyor components.
Description
- 36" (91.44 cm) wide
- Removable cast iron grid
- constructed of stainless steel
- Equipped with an 8.5-liter stainless steel water pan drawer
- Infinite control for every 12” of cooking surface
- Supplied with 4” (10.2 cm) high die cast nickel plated legs
- Two types of heat transfer, radiation direct from elements and conduction through the grates provide even heat distribution for maximum cooking performance
- 6 High performance, Incoloy sheath type heating elements
- Cool-to-the-touch stainless steel bull nose front provides knob protection and comfortable work zone
Product Specifications
General information
Voltage (V)
240
Machine Position
Counter Top
Country of Origin
USA
Manufacturer Warranty (Years)
2
Electricity
Power (W)
9900
Phase
1
Amperage (A)
27.6
Dimensions
Width (mm)
914
Height (mm)
412
Depth (mm)
650
About the brand
Star has been the leading manufacturer of restaurant equipment since 1921 in St. Louise, Missouri. They have an extensive range of products like the Star SWBS Waffle Maker, Star Max 548TGF Countertop Electric Toaster Griddle, and world-class Star Grooved Top & Bottom Panini Grill. Star is among the largest manufacturer of heavy-duty and high-quality kitchen equipment in the world. This is the best partner in helping you in your growing business.
Resources & Downloads
Great Warranty
2-year warranty with awesome service
Reliable Delivery
Free shipping when you spend 500 or above
Easy Returns
Easy returns within 14 days from delivery
Compare with similar products
Ekuep fulfilled
Star 5136CF, 36", Electric, Radiant CharbroilerThis Product |
| Price | 19,359.00 | 15,525.00 | 74,307.35 |
| Extended Ekuep Warranty | — | — | — |
| Free installation | ✓ | — | ✓ |
| Amperage (A) | 27.6 | 60 | N/A |
| Voltage (V) | 240 | 220 - 240 | N/A |
| Power (W) | 9900 | 400 | N/A |
| Machine Position | Counter Top | Counter Top | N/A |
| Phase | 1 | 3 | N/A |
| Width (mm) | 914 | N/A | N/A |
| Country of Origin | USA | Italy | N/A |
| Manufacturer Warranty (Years) | 2 | 2 | N/A |
| Height (mm) | 412 | 250 | N/A |
| Depth (mm) | 650 | 920 | N/A |
